Want to make your career by pursuing the ITI instrument mechanic course? If yes, and looking at the instrument mechanic ITI course’s complete details, you are at the right place. I will provide full info about the instrument mechanic ITI trade in this article.
ITI instrument mechanic is a skill-based course that consists study of various types of instruments used in installing, troubleshooting, and maintaining machinery. It is a course that comes under the mid-range category because the duration of ITI instrument mechanic is 2 years.
Like other ITI trades, the minimum educational qualification for taking admission in this trade is 10th. ITI instrument mechanic course is categorized under Craftsman Training Scheme (CTS) and affiliated with the Directorate General of Training (DGT).
- What is Instrument Mechanic in ITI?
- Instrument Mechanic ITI Duration
- Instrument Mechanic ITI Course Eligibility
- ITI Instrument Mechanic Syllabus
- Instrument Mechanic ITI Course Fees
- Instrument Mechanic ITI Job Scope
- ITI Instrument Mechanic Salary in India
- Instrument Mechanic ITI College
- Frequently Asked Questions
ITI Instrument Mechanic Course: Overview
| Course | ITI (Industrial Training Institute) |
| Trade Name | Instrument Mechanic |
| Course Level | Certificate |
| Course Duration | 2 Years |
| Eligibility | 10th |
| Admission Process | Direct/Merit/Entrance |
| Course Fees | ₹5,000 – ₹20,000 (Government) ₹5,000 – ₹50,000 (Private) |
| Jobs Salary | ₹10,000 – ₹15,000 per month |
What is Instrument Mechanic in ITI?
Instrument mechanic is a 2 years technical trade in ITI that deals with the study transformer, basics of electrical measuring instruments, meter range extension, transistors, rectifiers, voltage regulators, thyristor devices, types of amplifiers, oscillators, operational amplifiers, transducers, many more terms.
During the course, you will get theoretical as well as practical knowledge. Students get many experiences by doing practical training such as the construction and operation of capacitance probes indicating transmitters and sonic level detectors, installation, testing and calibration of ultrasonic flow meters, and calibrating the pneumatic DP transmitter for flow rate measurement.
Instrument Mechanic ITI Duration
The duration of the ITI instrument mechanic course is 2 years. The duration of 2 years is further divided into 4 semesters. Each semester consists of 6 months of duration.
| Course Element | 1st Year Hours | 2nd Year Hours |
|---|---|---|
| 1. Professional Skill (Trade Practical) | 1000 | 1000 |
| 2. Professional Knowledge (Trade Theory) | 280 | 360 |
| 3. Workshop Calculation & Science | 80 | 80 |
| 4. Engineering Drawing | 80 | 80 |
| 5. Employability Skills | 160 | 80 |
| Total | 1600 | 1600 |
Instrument Mechanic ITI Course Eligibility
Candidates must fulfil these eligibility criteria in order to get admission. The eligibility criteria are as follows:
- Candidates must be passed in 10th standard.
- Candidates should qualify from a recognized board of education.
- Candidates should get at least 40% marks in the exam.
- Candidates must be above 14 years of age.
Also Read:- ITI Refrigeration and Air Conditioning (RAC) Course
ITI Instrument Mechanic Syllabus
1st Year
Professional Skills
- Importance of trade training
- First aid method and basic training
- Hazard identification and avoidance
- Use of fire extinguishers
- Selection of material as per application
- Types of fasteners & fastening devices
- Familiar with drilling machine operation
- Select drill bits, reamers and tapes
- Drill through holes and blind holes
- Cutting and threading of tube joints
- Bending of tube cold and hot
- Identify and test different AC mains cables
- Practice soldering on IC bases and PCBs
- Join the broken PCB track and test
- Identify the primary and secondary cells
- Different types of inductors
- Construct and test RC time constant circuit
- Practice on speed control of single-phase AC motors
- Different types of torques
- Determine errors in meter movement
- Identify the different types of the ohm meter
- Calibrate various types of Ohm meter
- Test earth leakage by ELCB and relay
- Measure the power using a wattmeter
- Test and calibrate ampere-hour meter
- Construct and test common base amplifier
- Construct and test a FET amplifier
- Construct and test voltage doubler and tripler
- Install and test an inverter
- Check for cold continuity of PCB
- Display a word on a two-line LED
- Identify PC components and devices
- Measure the crystal frequency, connect it to the processor
Professional Knowledge
- Elementary first aid
- Safety and hazards
- Hazardous and non-hazardous
- Metal cutting fundamentals
- Measurement & measuring instruments
- Fasteners & fastening devices
- Electrical components
- D.C & A.C circuit differences
- Uses of multimeter
- Solder & flux
- Ohm’s law & Kirchhoff laws
- Switches and types
- Principles of alternating current
- Inductor and inductance
- Capacitors in DC circuit
- Introduction of AC and DC generators
- Speed controlling techniques of DC motors
- Transformer
- Basics of electrical measuring instruments
- Meter range extension
- Electro dynamometer applications
- Induction type meters
- Transistors
- Rectifiers
- Voltage regulators
- Power supply units
- Thyristor devices
- Types of amplifiers
- Oscillator’s
- Operational amplifier
- Number systems
- A/D and D/A converters
2nd Year
Professional Skills
- Identification of various instruments
- Identifying the measuring units of the instrument
- Identify the strain gauge type
- Check the strain gauge using ohm meter
- Determine the sensitivity
- Calibrate the LVDT by adjusting zero and span
- Measure the vibration of motor/machine
- Measure the speed of motor
- Measure the atmospheric pressure using barometer
- Identify the various types of manomters
- Calibrate the manometer using standard gauge
- Test & calibrate of pressure gauges
- Fault finding in pressure gauge
- Familiar with specifications of flow meter
- Measurement of flow rate using fixed volume tank
- Identifying various types of orifices
- Measurement of DP using DP gauge
- Identify and carry out preventive maintenance
- Testing and calibration of turbine flow meter
- Installation, testing and calibration of ultrasonic flow meter
- Service and calibrate solid flow meter
- Construct and operate conductivity probe level indicator
- Types of thermometers and measure the temperature
- Install and test various types of thermometers
- Construct and operate optical and radiation pyrometer
- Practice recording of variable signal
- Calibrating electronic recorder
- Calibrating current to pressure converter
- Record the characteristic of control valves
- Dismantle and assemble the desktop computer system
- Concept of tag/points generation
- Feature and function of hydraulic accumulator
- Installation of simple piping diagram
- Service and maintenance of conductivity meter
Professional Knowledge
- Scope and necessity of instrumentation
- Fundamental of measurement systems
- Fundamental units
- Temperature & electrical units
- Dynamic characteristics
- Types of errors
- Stress & strain measurement
- Principle of pressure in liquid & gases
- Electrical pressure transducers
- Low-pressure measurement
- Head type of flow meters
- Metering the flow of solid particles
- Principles of level measurement
- Pressure head instruments
- Temperature measurement
- Bimetallic thermometers
- Advantages & disadvantages of filled systems
- Electrical temperature instrument
- Molecular activity and electromagnetic radiation
- Thermal imagers
- Pneumatic and hydraulic actuators
- Control elements applications
- Introduction to controllers
- Controller models and tuning
- Introduction to programmable controllers
- Processing and programming functions
- Digital control systems
- Terminators and extra connectors
- Fundamentals of SCADA and DCS
- Terminology
- Basic Hydraulics
- Directional Control Valves
- Pneumatics principles
- Piping houses and fittings
- Conductivity meters
Instrument Mechanic ITI Course Fees
The course fees for ITI instrument mechanic trade mainly depend on which type of college you take admission. If you take admission to a government ITI college then the course fees is lesser as compared to a private ITI college. The average fees for both types of colleges are as follow:
- Government ITI:- ₹5,000 – ₹20,000
- Private ITI:- ₹5,000 – ₹50,000
Instrument Mechanic ITI Job Scope
You will find good job opportunities after the successful completion of the ITI instrument mechanic course. Industrialization is growing all over the nation by various means. Due to this, the rate of releasing job vacancies is also increasing. As far as the future job scope is concerned, it’s looking bright.
Also Read:- ITI Tractor Mechanic Course
ITI Instrument Mechanic Salary in India
The average salary that candidates get after completing the instrument mechanic ITI course is INR 10,000 to INR 15,000 on monthly basis. However, the salary depends on many factors such as skills, experience, behaviour, etc.
Average Salary:- ₹10,000 to ₹15,000 per month
Instrument Mechanic ITI College
| College Name | Location |
|---|---|
| 1. Government ITI for Girls | Nalgonda, Telangana |
| 2. Government ITI Jalandhar | Hoshiarpur, Punjab |
| 3. Government ITI | Thane, Maharashtra |
| 4. Government ITI | Satara, Maharashtra |
| 5. Government ITI Nachane | Ratnagiri, Maharashtra |
| 6. Government ITI | Cuttack, Maharashtra |
| 7. Government ITI Pardi | Valsad, Gujarat |
| 8. Government ITI Bilimora | Navsari, Gujarat |
| 9. Government ITI Vakadu | Tirupati, Andhra Pradesh |
| 10. Government ITI | Visakhapatnam, Andhra Pradesh |
Frequently Asked Questions
What can I do after ITI instrument mechanic?
You can either do a job or go for higher studies after completing ITI instrument mechanic course.
What is the duration of ITI instrument mechanic?
The duration of the ITI instrument mechanic course is 2 years. The duration of 2 years is further divided into 4 semesters. Each semester consists of 6 months of duration.
